Water heater/ Furnace sharing same flue pipe

1

Please correct me if I’m wrong! Isn’t the water heater pipe supposed to be lower than the furnace pipe when sharing the same flue?

IMG_3646
IMG_36463024×4032 492 KB

IMG_3513
IMG_35133024×4032 2.37 MB

2

The smaller unit (in BTU’s) should connect downstream of (or above in this case) the larger unit.

5 Likes
3

The only way to tell if the installation was done properly is to determine the BTUs of each unit?

2 Likes
4

Yes. The BTU ratings are on the data plates. At least in my area, the furnace will typically have the higher BTU rating.

1 Like
5

Typically the WH is the smaller unit and the flue should be above the furnace flue.

2 Likes
6

That is correct. The BTU can be found on the data plate of each appliance.

1 Like
7

Thanks! Here’s a doozie!

IMG_3661
IMG_36613024×4032 1.41 MB

1 Like
8

That is not the furnace flue.

5 Likes
9

Apparently you haven’t seen HVAC work in rural Georgia… :stuck_out_tongue: :wink:

6 Likes
10

Lol! Yea, amazes me at times!

1 Like
11

I’m assuming you mean the drain tube tapped into the side of the sink drain? What was it being used for?

1 Like
12

Good question! I have no idea. Plumber said it could be used as a condensate line drain. I told him that the car hose is in an apartment bathroom under sink. He replied “that’s strange.”

1 Like
13

Appears very similar to a commonly used dishwasher drain hose. I’m not sure I’d have an issue with the material.

https://www.supplyhouse.com/Sioux-Chief-906-7-8-ID-50-Coil-Dishwasher-Drain-Hose?utm_source=google_ad&utm_medium=pmax&utm_campaign=pmax_nca_test&gad_source=1&gclid=Cj0KCQiAqsitBhDlARIsAGMR1RhMotDw18cveUwEcIehRLn-eQv5EVmdszPa9BH7QphGlhHca9-txO0aAi7fEALw_wcB

2 Likes
14

But are we sure this is a dishwasher drain? I haven’t seen one exiting the back of a cabinet like that, but there are many things I haven’t seen before…except here. :wink:

1 Like
15

I also vote for dishwasher drain line, but if not, then maybe a condensation line or water softener drain line.

1 Like
16

I have no idea what it’s for. But if the hose is good enough for a dishwasher, it should be good enough for most things. The only one I would question would be HE furnace condensate maybe? Not sure if the acidic nature of that condensate would be detrimental to the hose.

2 Likes
17

Had one of those yesterday! Ran to the furnace…and that flue was also loose and not sitting on the exhaust. It was one of the “more wrong” installs I’ve seen lately!

Screenshot_20240126-091701_Gallery
Screenshot_20240126-091701_Gallery1080×1425 75.6 KB

Screenshot_20240126-092024_Video Player
Screenshot_20240126-092024_Video Player1080×1022 129 KB

18

Why did you run, was it that far?

19

LOL!! It was a ways!

Bruce Quinn, CMI, CCPI

Certified Master Inspector

Absolute Inspectors, LLC

(615)916-7264

[//cdck-file-uploads-global.s3.dualstack.us-west-2.amazonaws.com/internachi/original/4X/8/8/3/88302902e3c02715ad6ea69950ab8d7c608e7465.png] [//cdck-file-uploads-global.s3.dualstack.us-west-2.amazonaws.com/internachi/original/4X/8/2/0/82093c7a430c050d45c7c1eac184acc726e4a18d.jpeg] [//cdck-file-uploads-global.s3.dualstack.us-west-2.amazonaws.com/internachi/original/4X/2/6/c/26c6a22b4f170b3ae9a4cb8028ac22a2a17ba778.png]

20

Yep…
